Transmits HDMI signals up to 60m at 1080p and 35m at 4K@30 using Cat 6 cable
Supports HDMI Deep Color & full 3D & 4K@30 (HDBaseT technology)
HDMI Deep Color supports better color depths. To giving your display device a great image.
The extender supports Ultra HD and Full HD resolution
Transmits HDMI signals up to 60m at 1080p and 35m at 4K@30 using Cat 6 cable The extender supports Ultra HD and Full HD resolution and the accompanying digital audio.
Receiver can be powered directly by a power supply, or by Power over Ethernet from the transmitter
HBT-6 receiver can be powered by the same single power source using Power-over-Ethernet (PoE), easy to install for various applications. Support 12V power out for remotely located equipment.
HDCP compliant
Can perfectly display the video source with HDCP in high clarity with zero interruption.
Supports control over RS-232/ RS-422
HBT-6 offers RS-232/RS-422 control signals, which allow to control the source device from the display location.
Supports default EDID and EDID learning from the display
EDID pass-through passes signal between the source and display
Dolby TrueHD & DTS Master audio support
Supports Dolby Digital, DTS-HD and Dolby TrueHD audio
HDBaseT Compatibility List
The chart above shows the product’s direct compatibility with other HDBaseT products.
Datavideo’s Comprehensive HDBaseT Lineup
Experience a seamless live production future with Datavideo’s exceptional HDBaseT products. HDBaseT technology facilitates robust connectivity through advanced digital networking over existing cable infrastructure. Discover the excellence of our HDBaseT cameras, which deliver stunning 4K video and dynamic Auto Tracking with precision. The HS-1600T MKII switcher revolutionizes integration and control, making it simpler and more efficient. Datavideo’s HDBaseT lineup enhances live production with the power of uncomplicated, high-performance connectivity.
PRODUCT WORKFLOW
HDBaseT Receiver Box
Model Number
HBT-6
Video/Audio Input
HDBaseT RJ-45 x1
Video/Audio Output
HDMI x1
Supported Video Format
3840x2160p: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50, 720p: 60/59.94/50
525i59.94 NTSC, 625i50 PAL
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50, 720p: 60/59.94/50
525i59.94 NTSC, 625i50 PAL
Video Process
4K2K30 4:4:4 8bit
4K2K60 4:2:0 8bit
4K2K60 4:2:0 8bit
Video bandwidth
Single-link 340MHz [10.2Gbps]
DVIP
—
RS-422/ RS-232
YES
Power
DC IN: DC 48V
PoE Output
30W
HDBaseT Distance
1080p@60 60m (198ft) by CAT6 cable
4K2K@30 35m (114ft) by CAT6 cable
4K2K@30 35m (114ft) by CAT6 cable
HDMI compliance
HDMI Deep Color, full 3D & 4K2K@30
HDCP compliance
HDCP 2.2/1.4
Audio support
Surround sound [up to 7.1ch) or
stereo digital audio
stereo digital audio
Dimension (LxWxH)
88 x 76 x 30 mm
Weight
154 g
Operating Temp. Range
0~40 °C
What’s in the Box
1 x HBT-6 main unit
1 x AC cord
1 x DC 48V power adaptor
2 x Screw
1 x AC cord
1 x DC 48V power adaptor
2 x Screw
