LEADER PHRXM-4AES PHABRIX AES Module for PAHBRIX RXM

You can elevate your audio testing and monitoring capabilities with this advanced 4-channel AES (75-Ohms Unbalanced) Analyzer/Generator with AES Routing Module. This high-tech device is specifically designed for AES audio-centric installations, offering the ability to route 4x AES digital audio pairs to the Audio Meter and Loudness instruments, making it an ideal tool for audio professionals.

This sophisticated module also allows for the output of 4x AES digital audio pairs from the selected Analyzer/Generator module within the Rx chassis, enhancing the versatility of your audio testing setup. It is fully compatible with the Rx2000, Rx1000, and Rx500 instruments, extending the existing audio functionality of these instruments for a more comprehensive audio analysis experience.

The 4x AES digital audio pairs utilize 75ohm BNC connectors that accept AES sample rates ranging from 32kHz to 192kHz with 20 or 24-bit depth, providing you with a wide range of testing options. The module’s innovative sample rate conversion feature adjusts these inputs to deliver 48kHz AES audio for use by any installed module within the Rx chassis.

The 75ohm BNC connections are auto-sensing and can be used for both input and output of AES signals, offering you greater flexibility in your audio testing and monitoring processes. The AES audio can be accessed by any of the audio instruments of the HDMI monitor output. Moreover, the AES channels can be mapped to specific stereo pairs, 5.1, and 7.1 groups for precise measurement and monitoring using audio meters and loudness logging.

In essence, this professional-grade 4-channel AES Analyzer/Generator with AES Routing Module is a comprehensive solution for all your digital audio signal testing and monitoring needs.
