Lilliput PC‐1560 I3 – 15.6″ i3 Touchscreen Panel PC with High Brightness
€ 599,00 + VAT
The Lilliput PC1560 is a 15.6″ Windows 10 x86 Panel PC system designed for use in monitoring and control systems. Featuring a Core i3 2.1GHZ processor, 4GB RAM (expandable to 8GB) and a 120Gb mSATA drive it offers solid, reliable performance and delivers a sturdy “bang for buck”.
With an IP64 rating as standard, a 1920 x 1080 resolution LED panel with 1000 nit brightness, and a 10 point capacitive multi-touch screen it has solid HMI credentials and can be used in a number of industries – Medical, Smart lockers, Production, and in-vehicle farming systems.
 |
 |
 |
 |
 |
| Display | |
| Brightness | 1000 cdm² |
| Resolution | 1920 x 1080px |
| Touch Panel | 10 Point Capacitive Multi Touch |
| Viewing Angle | 160° / 160° |
| Connections | |
| Audio Output | Audio output × 1, green port |
| COM (DB-9) | COM1 supports RS232; COM2 supports RS232 / RS422 / RS485 |
| Mic Input | Microphone×1, red port |
| USB | USB2.0 host×2, USB3.0 host×2 |
| VGA Output | ×1, support up to 1080P 30Hz |
| HDMI Video Output | ×1, support up to 4K 30Hz |
| Panel PC Specifications | |
| Operating System | Windows 10 (unactivated) / Linux |
| Processor | Intel® Core i3-5015U, 2.1GHz dual-core processor |
| RAM Memory | 4GB (8GB Optional) |
| Internal Storage | 120GB mSATA |
| Graphics | Intel HD Graphics 5500 |
| Size | |
| Dimensions | 408mm×259mm×50.5mm |
| Weight | 5 Kg |
| Environment | |
| Operating Temperature | -10°C~60°C (14°F~140°F) |
| Storage Temperature | -20°C~70°C (-4°F~158°F) |
| Weight | 5000 g |
|---|
