| Suggested uses include retail & hospitality, intelligent industrial control systems, electronic assembly line controls, warehouse management, manufacturing – anywhere that people need to communicate. |
 |
| The front panel carries an IP65 protection rating which offers complete protection from particles, a good level of protection against projected water, and peace of mind for all environments – particularly when it comes to repeated spray down cleaning cycles and general hygiene. |
 |
| Built using the finest high-quality industrial-grade screens on the market, the Lilliput PC-2150 has an high brightness ratio of 1000cdm² – one of the highest brightness screens used in any Lilliput product – which makes it suitable for all outdoors and strong sunlight conditions. |
 |
| Panel PC Specifications | |
| Connections | 1x HDMI // 1x VGA // 3x USB 2.0 // 1x USB 3.0 // 1x LAN // 2x RS232 Serial Ports |
| Operating System | Windows 7 / 10, Linux Ubuntu (optional) – 32 Bit |
| Processor | Intel i3 2.0 GHz x86 |
| RAM Memory | 4GB DDR3 Up to 8GB |
| Internal Storage | 120GB mSATA (SATA 2.0 or 2.5″ HDD Options) |
| Graphics | Integrated Intel HD Graphics |
| I/O Connections (additional) | WLAN (802.11 a/b/g/n@2.4GHz // Bluetooth – 4.0 BLE |
| Screen Size (diagonal) | 21.5″ Full HD 10920 x 1080 1000 cdm² high brightness panel |
| Touchscreen Technology | 10 point multi-touch capacitive multi-touch supporting glove and rain responsiveness |
| Size | |
| Dimensions | 556 x 344.5 x 53mm |
| Weight | 7.25KG |
| Power | |
| Power Connector | DC 12V |
| Environment | |
| Operating Temperature | -10°c to 60°c |
| Storage Temperature | -20°c to 70°c |
