The Lilliput FA1330/T 13.3″ Full HD Touchscreen Commercial Monitor is a 300 nits bright display with 10-point capacitive touch suitable for a wide range of industrial and commercial applications, such as point of sale, kiosk, and heavy-duty industrial field equipment systems.
The FA1330/T can be used as a stand-alone monitor or as part of a larger, integrated system. Connect a wide range of computers and devices via HDMI, DisplayPort, and VGA inputs, with USB touch capability and support for Windows, Android, Linux, and MacOS. It features VESA 75mm mounting as well as 1/4″ mounting screw ports on both sides of the body, providing options for integrated solutions.
Key Specs
| Display Size |
13.3″
|
| Native Resolution |
1920 x 1080
|
| Maximum Brightness |
300 nits / cd/m2
|
| Touchscreen Technology |
Capacitive
|
| Inputs |
1x HDMI
1x DE-15/DB-15
1x DisplayPort
|
| Outputs |
1x 1/8″ / 3.5 mm (Headphone)
|
| Wireless |
No
|
| USB I/O |
1x USB-A (Unspecified Version) (Touchscreen Control)
|
| Ethernet I/O |
No
|
| Built-In Speakers |
Yes, 2
|
| Media Card Reader |
No
|
Display
| Display Size |
13.3″
|
| Panel Type |
LCD
|
| Aspect Ratio |
16:9
|
| Display Orientation |
Landscape
|
| Native Resolution |
1920 x 1080
|
| Maximum Brightness |
300 nits / cd/m2
|
| Contrast Ratio |
800:1
|
| Refresh Rate |
60 Hz
|
| Viewing Angle (H x V) |
170 x 170°
|
| Pixels Per Inch (ppi) |
166 ppi
|
Surface
| Touchscreen Technology |
Capacitive
|
| Multi-Touch Points |
10
|
| TV Tuner |
No
|
Connectivity
| Inputs |
1x HDMI
1x DE-15/DB-15
1x DisplayPort
|
| Outputs |
1x 1/8″ / 3.5 mm (Headphone)
|
| HDCP Support |
Yes
|
| Wireless |
No
|
| NFC |
No
|
| USB I/O |
1x USB-A (Unspecified Version) (Touchscreen Control)
|
| Ethernet I/O |
No
|
| Multi-Input Support (PIP/PBP) |
No
|
Speaker
| Built-In Speakers |
Yes, 2
|
| Speaker Configuration |
2-Channel
|
Hardware
| OS Compatibility |
Windows
macOS
Linux
|
| Mobile App Compatible |
No
|
| Media Card Reader |
No
|
| Built-In Mic |
No
|
Environmental
| Operating Temperature |
32 to 122°F / 0 to 50°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
Electrical
| Power Consumption |
Typical: < 12.0 W
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
7 to 24 VDC
|
| Power Adapter Type |
External
|
General
| Mounting-Hole Pattern |
75 x 75 mm
|
| Dimensions |
12.6 x 8.2 x 1″ / 320 x 208 x 26.5 mm
|
| Weight |
2.54 lb / 1.15 kg
|
Packaging Info
| Package Weight |
4.09 lb / 1856 g
|
| Box Dimensions (LxWxH) |
15 x 14.6 x 2.9″
|
