Lilliput PC7105 – 7″ panel PC with 1GHz processor
€ 448,00 + VAT
7″ LED Capacitive touch enabled All in one PC system available with Windows CE 6.0 / Android 2.3 / Linux 2.6.32. A good solid performer, the PC7105 is one of the best performing panel PC systems that Lilliput have produced, and a stable system for all industrial / automation uses.
- Ideal for industrial monitoring and control / in vehicle ticketing systems
- Display, Control, Communicate and play multimedia – all from a single robust unit
- Using stable ARM Cortex technology for 800Mhz to 1Ghz performance
- High integration capability
  |
|---|
| Display | |
| Brightness | 450 cdm² |
| Display Screen | 7″ TFT LCD 16:9 Aspect Ratio |
| Resolution | 800 x 480 px |
| Touch Panel | Resistive |
| Panel PC Specifications | |
| Operating System | Windows CE / Android 2.3 / Linux 2.6.32 |
| Processor | Telechip 8803 1.0GHz – Core = Arm Cortex 8 |
| RAM Memory | 512MB DDR3 |
| Internal Storage | 2GB NAND Flash + SD Card Port |
| Networking | LAN : Ethernet 10/100M |
| Interface | |
| Slots and Jacks | USB 2.0 Host = 2x / USB Device 2.0 = 1x / RS232 = 3x / RS232 = 2x / RS485 = 1x |
| Common Parameters | |
| Dimension | 200 (L x 128 (W) x 36 (D) |
| Power | 9-24V DC 5.5mm x 2.1mm Power Jack / 9W Consumption |
| Weight (g) | 1.2 KG |
| Weight | 1200 g |
|---|
