Lilliput TK701/T – 7″ HDMI Capacitive Touch Monitor with Wall Mount Kit
€ 197,00 + VAT
- 16:10 Aspect Ratio/800 x 480 Resolution
- AV, VGA, and HDMI Inputs
- Up to 2160p30 HDMI Input
- Metal Housing and IP64-Rated Screen
The TK701/C/T 7″ Industrial 1000 cd/m² Touchscreen Monitor from Lilliput features a 16:10 aspect ratio, 800 x 480 resolution, and 1000 cd/m² high brightness. This touch model has a 10-point touchscreen panel allowing for capacitive touch efficiency. The monitor has a metal housing and an IP64 screen rating, which provides full dust protection and a degree of protection against water. The monitor offers AV, VGA, and HDMI inputs, with the HDMI interface supporting up to 2160p30 2K resolution.
| Display | |
| Aspect Ratio | 16:10 |
| Brightness | 1000 nits |
| Contrast Ratio | 1000:1 |
| Resolution | 800×480 |
| Touch Panel | Optional, 10-point capacitive touch |
| Viewing Angle | 140° / 120° |
| HDMI Video Input | |
| Formats | 2160p 24/25/30, 1080p 24/25/30/50/60, // 1080i 50/60, 720p 50/60… |
| Connections | |
| Audio | x1 |
| HDMI Video Input | 1 × HDMI 1.4b |
| VGA Video Input | x1 |
| A/V Input | x1 |
| Audio | |
| Speaker | x1 |
| Size | |
| Dimensions | 210mm × 131mm × 34.2mm |
| Weight | 1000g |
| Power | |
| Power Consumption | ≤8.5W (12V) |
| Environment | |
| IP Rating | IP64 |
| Operating Temperature | -20°C~60°C (-4°F~140°F) |
| Storage Temperature | -30°C~70°C (-22°F~158°F) |
| Weight | 1000 g |
|---|
